Key points

• Form factor: micro-ATX

• Chipset: Intel H610

• Socket: LGA1700

• Memory: 2× DDR5, dual-channel, up to 64 GB (JEDEC up to ~4800 MT/s)

Expansion slots

• 1× PCIe x16 (CPU): PCIe 4.0 x16

• 1× PCIe x1 (chipset): PCIe 3.0 x1

Storage

• 1× M.2 NVMe PCIe 3.0 x4

• 4× SATA 6 Gb/s

Video outputs (from the motherboard)

• HDMI

• D-Sub (VGA)

Network & audio

• LAN: Gigabit Ethernet

• Audio: HD codec (3 rear jacks)

Rear connectivity (typical I/O)

• USB: 4× USB 3.2 Gen1 + 2× USB 2.0

• Video: 1× HDMI, 1× VGA

• Network: 1× RJ-45

• Audio: 3 jacks

• Other: PS/2 combo

Internal headers

• Front USB: 1× USB 3.2 Gen1 header (2 ports) + 2× USB 2.0 headers (4 ports)

• Fans: 1× CPU_FAN + 1× SYS_FAN

• Other: front audio, F-Panel, TPM (SPI)
